Baader Pushfix Reducer 2" to 1¼" (T-2 part #15a) - 2408151
Highlights
Ideal for Newton Focuser e.g. Baader Newton Crayford focusers with only 1mm optical path length
Provides three separate mounting optios for 1¼" accessories
Side clamping screw and brass clamping ring for secure grip. Also includes countersunk grub screws for permanent or quick release operation of the brass clamping ring.
The countersunk Delrin grub screws allow for the pressure to be set correctly. This acts as a quick release without relying on set screws. When an eye piece is inserted it is held securely and safely while still allowing the eye piece to be removed.
Specifications
| Manufacturer | Baader Planetarium |
|---|---|
| SKU (#) | 2408151 |
| EAN Code | 4047825020734 |
| Weight (kg) | 0.107 |
| Optical length (mm) | 1 |
| Clamping System | Screw clamps |
| T-2 Part # | 15A |
| Usage | Suitable for Newton focusers |
| Screw Type | M4 clamping screw and Delrin pressure screws |
| Inner Diameter / Clear Aperture (mm) | 31,75 (1¼") |
| Outer Diameter | 54 |
| Inner Connection (lens sided) | Thread, T-2 (M42 x 0,75), M48 |
| Outer Connection (lens sided) | Barrel, 2" (50,8mm) |
| Inner Connection (eyepiece/-camera-sided) | Clamp, 1¼" |
| Compatible Brands | Astro T-2, UNC, Baader Planetarium, Celestron |
| Type of Adapter | Eyepiece Clamp, Filter holder, Reducing piece |
Original: $40.56
-65%$40.56
$14.20Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Highlights
Ideal for Newton Focuser e.g. Baader Newton Crayford focusers with only 1mm optical path length
Provides three separate mounting optios for 1¼" accessories
Side clamping screw and brass clamping ring for secure grip. Also includes countersunk grub screws for permanent or quick release operation of the brass clamping ring.
The countersunk Delrin grub screws allow for the pressure to be set correctly. This acts as a quick release without relying on set screws. When an eye piece is inserted it is held securely and safely while still allowing the eye piece to be removed.
Specifications
| Manufacturer | Baader Planetarium |
|---|---|
| SKU (#) | 2408151 |
| EAN Code | 4047825020734 |
| Weight (kg) | 0.107 |
| Optical length (mm) | 1 |
| Clamping System | Screw clamps |
| T-2 Part # | 15A |
| Usage | Suitable for Newton focusers |
| Screw Type | M4 clamping screw and Delrin pressure screws |
| Inner Diameter / Clear Aperture (mm) | 31,75 (1¼") |
| Outer Diameter | 54 |
| Inner Connection (lens sided) | Thread, T-2 (M42 x 0,75), M48 |
| Outer Connection (lens sided) | Barrel, 2" (50,8mm) |
| Inner Connection (eyepiece/-camera-sided) | Clamp, 1¼" |
| Compatible Brands | Astro T-2, UNC, Baader Planetarium, Celestron |
| Type of Adapter | Eyepiece Clamp, Filter holder, Reducing piece |
